PC

Polycarbonate
High-temp · High-strength

Polycarbonate is what we reach for when a part runs hot and still has to carry load. Heat deflection of 114 °C at 0.45 MPa, and the highest impact strength in our FDM lineup.

Quote in PC →All FDM materials
FDMPCBlackManifoldBlack 3D-printed engine intake manifold with mounting flanges and runner openings
SECTION · 01

Strengths
& uses

Where the temperature goes up, the loads get serious, or both at the same time.

Strengths
  • Heat deflection 114 °C at 0.45 MPa — 99 °C under a 1.8 MPa load
  • High strength and stiffness
  • Charpy impact 21.28 kJ/m² — the highest of our FDM materials
  • Dimensionally stable under sustained heat and load
Common applications
  • High-temp brackets
  • Under-hood automotive
  • Industrial heat shields
  • Structural prototypes
SECTION · 02

Compare with
other FDM
materials

PC measured against the FDM core lineup.

Material
Economical
Max Size
Flexibility
Strength
Heat Resistance
PLA
PLA Pro
PETG
PET-CF
ESD-Safe PETG
ABS
ASA
PC
PA6-CF
TPU
SECTION · 03

Technical
Specifications

Manufacturer datasheet values. Real-world performance will vary — see disclaimer.

Mechanical
Properties
(XY) Tensile Modulus
2435 ± 63 MPa
ISO 527, GB/T 1040
(XY) Tensile Strength
53.44 ± 0.60 MPa
ISO 527, GB/T 1040
(XY) Elongation at Break
4.53 ± 0.45 %
ISO 527, GB/T 1040
(XY) Bending Modulus
2050 ± 79 MPa
ISO 178, GB/T 9341
(XY) Bending Strength
81.29 ± 1.53 MPa
ISO 178, GB/T 9341
(XY) Charpy Impact Strength
21.28 ± 1.69 kJ/m²
ISO 179, GB/T 1043
Thermal
Properties
Glass Transition Temperature
113 °C
DSC 10°C/min
Decomposition Temperature
>360 °C
TGA 20°C/min
Vicat Softening Temperature
116.9 °C
ISO 306, GB/T 1633
Heat Deflection Temperature (1.8 MPa)
99.3 °C
ISO 75, 1.8 MPa
Heat Deflection Temperature (0.45 MPa)
114.1 °C
ISO 75, 0.45 MPa
Chemical
Resistance
Weak Acids
Slightly resistant
Strong Acids
Not resistant
Weak Alkalis
Slightly resistant
Strong Alkalis
Not resistant
Organic Solvent
Not resistant
Oils and Grease
No data available
Equilibrium Water Absorption
0.253 %

* Actual part performance varies with geometry, build orientation, layer height, infill, and post-processing. For load-bearing or safety-critical applications, contact us for part-specific validation.

Source: Polymaker PolyMax PC datasheet (V5.3) ↓
